Dutch Weave 300 Mesh Count Stainless Steel Wire Mesh Filter

Dutch Weave 300 Mesh Count Stainless Steel Wire Mesh Filter
Dutch Weave 300 Mesh Count Stainless Steel Wire Mesh Filter Dutch Weave 300 Mesh Count Stainless Steel Wire Mesh Filter Dutch Weave 300 Mesh Count Stainless Steel Wire Mesh Filter

Large Image :  Dutch Weave 300 Mesh Count Stainless Steel Wire Mesh Filter

Product Details:
Place of Origin: Hebei,China
Brand Name: YuanHai
Certification: ISO9001
Model Number: YH-32
Payment & Shipping Terms:
Minimum Order Quantity: 30 Square Meters
Price: Negotiable
Packaging Details: packing in roll and plastic inside and wooden case outside or as your requirement
Delivery Time: 3-10days
Payment Terms: T/T
Supply Ability: 20000 Square Meter/Square Meters per Month
Detailed Product Description
Material: SS 302,304,316,304L,316L,321 Weaving: Plain,twill Or Dutch
Feature: Eco Friendly Usage: Liquid Filter
Certificate: ISO9001:2015 Brand: Yuanhai
High Light:

30m stainless steel filter mesh

,

30m Stainless Steel Wire Mesh Filter

High Grade Dutch Weave SS Wire Mesh 200 300 Mesh Count




Stainless Steel Wire Mesh Filter Description



We produce stainless steel wire mesh from first class stainless steel material in SUS/AISI 201 202 302 304 310 310S 316 316L 321 430 etc.

Stainless steel wire mesh with its excellent resistance against acid, alkali, heat and corrosion, extensively used in processing of oil, chemical, food, making wire mesh filter, also sorting and screening of solid, liquid and gas in mine, metallurgy, airspace and machine making etc.



Weave Style



1. Plain Weave: also called tabby weave, linen weav or taffeta weave, is the most basic type of weaves. In plain weave, the warp and weft are aligned so they form a simple criss-cross pattern. Each weft thread crosses the warp threads by going over one, then under the next, and so on. The next weft thread goes under the warp threads that its neighbor went over, and vice versa.
2. Twill Weave: In a twill weave, each weft or filling yarn floats across the warp yarns in a progression of interlaces to the right or left, forming a distinct diagonal line. This diagonal line is also known as a wale. A float is the portion of a yarn that crosses over two or more yarns from the opposite direction.
3. Plain Dutch Weave: similar with plain weave, just the weft and warp wire have different wire diameter and different mesh size.
4. Twill Dutch Weave: similar with twill weave, just the weft and warp wire have different wire diameter and different mesh size.
5. Reversed Dutch Weave: difference from standard Dutch weave lies in the thicker warp wires and less weft wires.



Specification of Stainless Steel Wire Mesh Filter



Stainless Steel Wire Mesh
Mesh/inch Wire Diameter
(mm)
Aperture
(mm)
  Mesh/inch Wire diameter
(mm)
Aperture
(mm)
2mesh 1.80 10.90   60mesh 0.15 0.273
3mesh 1.60 6.866   70mesh 0.14 0.223
4mesh 1.20 5.15   80mesh 0.12 0.198
5mesh 0.91 4.17   90mesh 0.11 0.172
6mesh 0.80 3.433   100mesh 0.10 0.154
8mesh 0.60 2.575   120mesh 0.08 0.132
10mesh 0.55 1.990   140mesh 0.07 0.111
12mesh 0.50 1.616   150mesh 0.065 0.104
14mesh 0.45 1.362   160mesh 0.065 0.094
16mesh 0.40 1.188   180mesh 0.053 0.088
18mesh 0.35 1.060   200mesh 0.053 0.074
20mesh 0.30 0.970   250mesh 0.04 0.061
26mesh 0.28 0.696   300mesh 0.035 0.049
30mesh 0.25 0.596   325mesh 0.03 0.048
40mesh 0.21 0.425   350mesh 0.03 0.042
50mesh 0.19 0.318   400mesh 0.025 0.0385
Width of Stainless Steel Wire Mesh: 0.6m-8m





Stainless Steel Wire Mesh Filter Application

  • In acid, alkali environment conditions sieving and filtering.
  • Petroleum industry as mud mesh,.
  • Chemical fiber industry as screen mesh.
  • Plating industry as acid cleaning mesh.

the Stainless Steel Wire Mesh Feature

  • Corrosion resistance.
  • Anti-acid and alkali resistance
  • Anti-high temperture.
  • Good filter performance.
  • Long using life

The common packaging


1.30m/roll in PVC bag
2.2-8 rolls per carton
3.waterproof bags outside
4.package belt strengthen



Dutch Weave 300 Mesh Count Stainless Steel Wire Mesh Filter 0
