| Material: | Stainless Steel,low Carbon Wire | Characteristics: | Hard And Beautiful And Sharp |
|---|---|---|---|
| Usage: | Security And Ety | Surface: | Galvanized/PVC Coated |
| Coil Diameter: | 360-1000mm | Zinc Coating: | 40-280g/m2 |
| Highlight: | 500mm Razor Barbed Wire,500mm razor blade barbed wire,Concertina Razor Barbed Wire |
||
Concertina Razor Wire Razor Barbed Wire Fencing 500mm Coil Diameter
Razor Barbed Wire Description
Razor Barbed Wire is also named concertina razor wire, razor fencing wire, razor blade wire or dannert wire. It is a kind of modern security fencing materials with better protection and fencing strength made of hot-dipped galvanized steel sheets or stainless steel sheets. With sharp blades and strong core wire, razor wire has the features of secure fencing, easy installation, age resistance and other properties.
Razor Barbed Wire Specification
| Reference Number |
Thickness mm |
Wire Dia. mm |
Barb Length mm |
Barb Width mm |
Barb Spacing mm |
| BT0-12 | 0.5±0.05 | 2.5±0.1 | 12±1 | 15±1 | 26±1 |
| BT0-15 | 0.5±0.05 | 2.5±0.1 | 18±1 | 15±1 | 33±1 |
| BT0-22 | 0.5±0.05 | 2.5±0.1 | 22±1 | 15±1 | 34±1 |
| BT0-30 | 0.5±0.05 | 2.5±0.1 | 30 | 18 | 45±1 |
| CBT-60 | 0.6±0.05 | 2.5±0.1 | 60±2 | 32±1 | 100±2 |
| CBT-65 | 0.6±0.05 | 2.5±0.1 | 65±2 | 21±1 | 100±2 |
| Outer diameter | No.of Loops |
Standard Length per Coil |
Type | Notes |
| 450mm | 33 | 7M-8M | CBT-65 | Single coil |
| 500mm | 41 | 10M | CBT-65 | Single coil |
| 700mm | 41 | 10M | CBT-65 | Single coil |
| 960mm | 54 | 11M-15M | CBT-65 | Single coil |
| 500mm | 102 | 15M-18M | BTO-12.18.22.28.30 | Cross type |
| 600mm | 86 | 13M-16M | BTO-12.18.22.28.30 | Cross type |
| 700mm | 72 | 12M-15M | BTO-12.18.22.28.30 | Cross type |
| 800mm | 64 | 13M-15M | BTO-12.18.22.28.30 | Cross type |
| 960mm | 52 | 12M-15M | BTO-12.18.22.28.30 |
Cross type |
Razor Barbed Wire Feature
Galvanized Barbed wire offers a great protection against corrosion and oxidation caused by the atmosphere. Its high resistance allows greater spacing between the fencing posts.
Razor Barbed Wire Packing Details
1. compression rolls, 5rolls, 10rolls, or more rolls as one bundle
2. water-proof paper inside with woven bag outside
3. 1roll, 3rolls or 5rolls in one carton
4. as customer request
Razor Barbed Wire Application
Razor wire tape is widely used in gardens, hospitals, industrial and mining enterprises, prisons, border posts, detention centers, government building or other security facilities.
Also used for division of railway, highway, agricultural fencing, etc.
Surface Treatment
Hot Dip Galvanized PVC Coating
Razor Barbed Wire Usage
