Heavy Gauge Small Hole Welded 358 Security Fencing

Description of 358 Security Fencing

Anti climb fence is also called 358 fence or anti climb fence, this system is extensively used when defendable space is
paramount, used throughout the world in varying applications.

The climb resistant mesh (sometimes referred to as prison mesh or 358 mesh) with its small apertures and welds at each intersection eliminate foot and finger holds, prevent objects being passed through and is particularly effective against the use of conventional hand cutting tools.

Specifications of 358 Security Fencing

Standard Specification of 358 Security Fencing

Length: 2000x2200mm
Wire diameter: 4mm
Mesh Size: 12.7x76.2mm
Surface Treatment: electro galvanized wire welded, then PVC coated
Fence Post: 60x60x2x2500mm
Surface Treatment:galvanized pipe PVC coated
Flat Bar:60x5x2000mm
Surface Treatment: Iron flat bar PVC coated
With Plastic cap and bolts and nuts

Features of 358 Security Fencing

1.Anti-climbing - Due to the high-density mesh of the 358 guardrail, it is impossible to grasp the hands and feet, which plays a very good protection against climbing.

2.Anti-shear - the wire diameter is large, the mesh is dense, making the wire cut useless.

3.Beautiful appearance - the mesh surface is flat, and the perspective is higher.

Surface treatment

1> Electric Galvanized Then PVC Coated(powder thickness 0.1mm)
2>Electric Galvanized Then Powder Coated(powder thickness 0.8-1.2mm)
3>Hot Dipped Galvanized Then PVC Coated(powder thickness 0.1mm)
4>Hot Dipped Galvanized Then Powder Coated(powder thickness 0.8-1.2mm)
5>Hot Dipped Galvanized After Welded(zinc coating: 40-500g/m²)
