Hexagonal Galvanized 3/4 Flattened Aluminum Expanded Wire Mesh For Industry

Large Image : Hexagonal Galvanized 3/4 Flattened Aluminum Expanded Wire Mesh For Industry

Product Details:

Place of Origin:	Hebei,China
Brand Name:	YuanHai
Certification:	ISO9001:2008
Model Number:	YH-06

Payment & Shipping Terms:

Minimum Order Quantity:	50 Square Meters
Price:	US$4~20
Packaging Details:	palletized or loose load in the container
Delivery Time:	3-8 days
Payment Terms:	T/T
Supply Ability:	100000 Square Meters per Week

Chat Now

Detailed Product Description

Material:	Stainless Steel Plate , Aluminium Plate,common Carbon Plate	Hole Shape:	Diamond / Hexagonal
LWD:	25mm-100mm	SWD:	10mm-50mm
Weight:	0.7kg-30kg/㎡	Thickness:	0.3mm-8mm
Process:	Cutting, Punching	Surface Treatment:	Hot Dipped Galvanized, Powder Coated
Product Name:	Expanded Aluminium/ Stainless Steel Sheet	Usage:	Construction,building Facade,guard, Filter Net
Size:	Customized	Brand Name:	Yuanhai
Place Of Origin:	Hebei Province,China	Certification:	ISO9001:2015
Highlight:	flattened aluminum expanded metal mesh , hexagonal aluminum expanded wire mesh , 3/4 aluminum expanded wire mesh

Galvanized 3/4 Flatten Expanded Stretched Diamond Metal Mesh For Industry

Product Description of Expanded Metal Sheet

Expanded metal sheets are created by slitting and cold-forming metal as it expands in a press. This process creates diamond-shaped openings that are nominally measured the long way of the diamond (LWD) and the short way of the diamond (SWD). Raised, or standard, expanded sheets offer a skid-resistant surface and a high strength-to-weight ratio. Flat expanded sheets have been rolled for a smooth, level surface. Expanded metal sheets are measured by the percentage of open area, which is the ratio of open space to total space in a given area. A sheet with a larger percentage of open area contains less material than one with a smaller percentage.

Specification of Expanded Metal Sheet

L.W.M.	S.W.M.	Strand Width	Strand Gauge	Approx. Kg/M2
6.05	3.38	0.8	0.5	2.1
10.24	5.84	0.8	0.5	1.2
10.24	5.84	1.2	0.9	3.2
14.27	5.84	1.2	0.9	3.2
19.05	7.42	1.2	0.9	3.4
5.8	3.5	0.8	0.6	2.1
19	7.4	1.7	1.0	3.4
30.5	11.7	2.4	1.6	4.9
30.5	11.7	2.4	1.2	3.8
38	16.5	2.2	1.6	3.4
50.8	22.5	2.5	2.5	4.4
50.8	22.5	3	1.6	3.4
50.8	22.5	3.9	3	8.1
50.8	22.5	3.1	3	6.5
76.2	33.9	3.5	3	4.9
85.7	40.6	3.2	3	3.7
101.6	50.8	5	3	4.7
101.6	50.8	3.4	3	3.1
114.3	39.3	4.6	3	5.4
200	75	6.3	3	3.6

Features of Expanded Metal Mesh

1)Strong and durable, with Elegant appearance

2)Easy maintenance, high visibility.

3)Antioxidant and corrosion resistant, long lifetime.

4)Convenient installation, and not easy to be damaged.

5)Environmental protection product, can be recycled.

Application of Expanded Metal Sheet

Protective cover
Metal fence
Metal grille
Walkway
Building Facades
Supermarket shelves
Bicycle basket
Trailer floor and sides

Package of Expanded Metal Sheet

1. On pallet with waterproof cloth,the biggest width is 1500mm

2. In wooden case with waterproof paper

3. In carton box

4. In roll with woven bag,the biggest width is 3000mm

5. In bulk or In bundle

Hexagonal Galvanized 3/4 Flattened Aluminum Expanded Wire Mesh For Industry 0

Hexagonal Galvanized 3/4 Flattened Aluminum Expanded Wire Mesh For Industry 1

Hexagonal Galvanized 3/4 Flattened Aluminum Expanded Wire Mesh For Industry 2

Hexagonal Galvanized 3/4 Flattened Aluminum Expanded Wire Mesh For Industry 3

Hexagonal Galvanized 3/4 Flattened Aluminum Expanded Wire Mesh For Industry 4
