Low Carbon Cross Type Hot Dip Galvanized Razor Wire 500mm Coil Diameter 22mm±1mm

China Anping yuanhai wire mesh products Co., Ltd certification
China Anping yuanhai wire mesh products Co., Ltd certification
Thanks for your kindly hospitality. Your company is very professional , we are very satisfied with your expanded metel sheet, we will have nice cooperation in the near future.

—— Roger Hopkins

Good company with nice service and high quality and high reputation. The stainless steel wire mesh is good quality,one of our reliable supplier , goods are delivered in time and nice package.

—— Mr.mosharaf hossain

Received ur Gabion Mesh,Thanks for your good after-sale service. Excellent training and technology support helps me a lot.

—— Tshediso Sedie

I'm Online Chat Now

Low Carbon Cross Type Hot Dip Galvanized Razor Wire 500mm Coil Diameter 22mm±1mm

Low Carbon Cross Type Hot Dip Galvanized Razor Wire 500mm Coil Diameter 22mm±1mm
Low Carbon Cross Type Hot Dip Galvanized Razor Wire 500mm Coil Diameter 22mm±1mm Low Carbon Cross Type Hot Dip Galvanized Razor Wire 500mm Coil Diameter 22mm±1mm

Large Image :  Low Carbon Cross Type Hot Dip Galvanized Razor Wire 500mm Coil Diameter 22mm±1mm

Product Details:
Place of Origin: AnPing,China
Brand Name: YuanHai
Certification: ISO 9001
Model Number: YH005
Payment & Shipping Terms:
Minimum Order Quantity: 200rolls
Price: Negotiable
Packaging Details: Waterproof paper or as customer's request
Delivery Time: 3-10days
Payment Terms: T/T
Supply Ability: 20000 Roll/Rolls per Month
Detailed Product Description
Material: Iron Wire, Low Carbon Steel Blade Type: CBT--65;BTO-22;BTO-28;BTO-30;
Surface Treatment: Galvanized/PVC Coated Zinc Coated: Galvanized Wire:8-60g/m2;Blade:40-60g/m2
Razor Thickness: 0.45±0.05mm Razor Barb Length: 22±1mm
Razor Barb Spacing: 34±1mm Use: Protecting Buliding;Grass Boundary,Railway,Highway,Army Etc
Certification: ISO9001:2015 Package: Inner Waterproof Paper With Woven Bag Outside
Type: Single/Cross Place: Hebei Province
High Light:

hot dip galvanized razor wire

,

galvanized razor wire 500mm coil diameter

,

cbt 65 concertina barbed tape



Galvanized Military Conductive Razor Barbed Wire 900mm Coil Thermal CBT-65 Type




Product Description of Razor Barbed Wire

Razor barbed wire is a kind of modern security fencing materials fabricated with razor-sharp steel blade and high-tensile wire. It can be installed to achieve the result of frightening and stopping to the aggressive perimeter intruders, with piecing and cutting razor blades mounted at the top of the wall, also the special designs making climbing and touching extremely difficult. The wire and strip are galvanized or PVC coated to prevent corrosion.

Blade Style
of Razor Barbed Wire

Specification



Reference Number Thickness Wire Dia Barb
Length
Barb
Width
Barb
spacing
BTO-10 0.5±0.05 2.5±0.1 10±1 13±1 25±1
BTO-12 0.5±0.05 2.5±0.1 12±1 15±1 25±1
BTO-18 0.5±0.05 2.5±0.1 18±1 15±1 35±1
BTO-22 0.5±0.05 2.5±0.1 22±1 15±1 36±1
BTO-28 0.5±0.05 2.5 28 15 46±1
BTO-30 0.5±0.05 2.5 30 18 46±1
CBT-65 0.6±0.05 2.5±0.1 65±2 21±1 101±1



Outside Diameter
No.of Loops

Standard Length per Coil
Type
Notes
450 mm
33



8m
CBT-65
Single coil
500 mm
41
10m
CBT-65
Single coil
700 mm
41
10m
CBT-65
Single coil
960 mm
53
13m
CBT-65
Single coil
500 mm
102
16m
BTO-10.15.22
Cross type
600 mm
86
14m
BTO-10.15.22
Cross type
700 mm
72
12m
BTO-10.15.22
Cross type
800 mm
64
10m
BTO-10.15.22
Cross type
960 mm
52
9m
BTO-10.15.22
Cross type



Advantages of Razor Barbed Wire



1.Anti Theft

2.Anti Climb

3.Preservative

4.High Temperature Resistance

5.Easy to Install

6.Defense Invasion



Types of Razor Barbed Wire



Single Coil Razor Wire
Single coil Concertina Wire is installed without clips, it runs in natural loops on walls.Cost less and can be easily installed.
Crossed Razor Wire
Two pieces of razor wire were bounded together by clips to make it more strength.The spiral intersecting barbed wire presents an
intersecting shape after opening with beautiful feature and practicality.
Flat warp razor wire
Flat warp razor wireis a new type of razor barbed wire. Press two loops into flat then expand them across. We usually use it
together with been line razor barbed wire to build a defending wall, or use it alone as a fence.



Packing and Shipping of Razor Barbed Wire



1. Each roll with inner waterproof paper and woven bag outside, then 50rolls or 100roll be a bundle by metal strip.

2. Be bundled razor wire put on pallet.
3. Bulk razor wire put into cartons.
4. Packaged razor wire barrier into wooden case.
5. Bulk waterproof paper inner with woven bag outside razor rolls loaded in 40'HQ/27tons


Application of Razor Barbed Wire



Once invented in history, barbed wire has been widely used in military and defense projects; now in the peaceful era, barbed wire is alternately used in machinery, electronics, pharmaceuticals, petrochemicals, glass, food drying, plastics, paper, chemical fiber, picture tubes and other industries.
Barbed wire is also widely used in various aspects of agriculture and life. Recently, barbed wire is used in rock planting. On the rock slope, the new technology of holding wire mesh and spraying powder and planting grass is adopted to achieve slope protection and at the same time play the effect of beautifying the environment.





Low Carbon Cross Type Hot Dip Galvanized Razor Wire 500mm Coil Diameter 22mm±1mm 0







Low Carbon Cross Type Hot Dip Galvanized Razor Wire 500mm Coil Diameter 22mm±1mm 1



Low Carbon Cross Type Hot Dip Galvanized Razor Wire 500mm Coil Diameter 22mm±1mm 2


Packing & Delivery of Razor Barbed Wire


Low Carbon Cross Type Hot Dip Galvanized Razor Wire 500mm Coil Diameter 22mm±1mm 3

We use 3 common packages or as customer's request.

Low Carbon Cross Type Hot Dip Galvanized Razor Wire 500mm Coil Diameter 22mm±1mm 4

Company Profile

1. Is your company a manufacturer or a trading company?
We are a manufacturer located in Anping County, China.
2. Do you have inport-export right?
Yes, we do. Our factory has been certificated as an import-export enterprise.
3. What is your payment mode?
30% in advance and 70% before delivery by T/T, WESTERN UNION, L/C or negotiated.
4. How about your packing?
We usually packed in plastic material inside and then wooden box outside.
5. How long is your delivery?
Usually 10-20 days after order confirmed, according the quantity ordered.
6. Is it sample available?
Yes, small pieces of sample are available in our company.
