Bto-22 Razor Coil Barbed Wire Pvc Coated 500mm Diameter For Private House

China Anping yuanhai wire mesh products Co., Ltd certification
China Anping yuanhai wire mesh products Co., Ltd certification
Thanks for your kindly hospitality. Your company is very professional , we are very satisfied with your expanded metel sheet, we will have nice cooperation in the near future.

—— Roger Hopkins

Good company with nice service and high quality and high reputation. The stainless steel wire mesh is good quality,one of our reliable supplier , goods are delivered in time and nice package.

—— Mr.mosharaf hossain

Received ur Gabion Mesh,Thanks for your good after-sale service. Excellent training and technology support helps me a lot.

—— Tshediso Sedie

I'm Online Chat Now

Bto-22 Razor Coil Barbed Wire Pvc Coated 500mm Diameter For Private House

Bto-22 Razor Coil Barbed Wire Pvc Coated 500mm Diameter For Private House
Bto-22 Razor Coil Barbed Wire Pvc Coated 500mm Diameter For Private House Bto-22 Razor Coil Barbed Wire Pvc Coated 500mm Diameter For Private House

Large Image :  Bto-22 Razor Coil Barbed Wire Pvc Coated 500mm Diameter For Private House

Product Details:
Place of Origin: AnPing,China
Brand Name: YuanHai
Certification: ISO 9001
Model Number: YH005
Payment & Shipping Terms:
Minimum Order Quantity: 200rolls
Price: Negotiable
Packaging Details: Waterproof paper or as customer's request
Delivery Time: 3-10days
Payment Terms: T/T
Supply Ability: 20000 Roll/Rolls per Month
Detailed Product Description
Material: Iron Wire, Low Carbon Steel Q195 Blade Type: CBT--65;BTO-22;BTO-28;BTO-30;
Surface Treatment: Galvanized/PVC Coated Zinc Coated: Galvanized Wire:8-60g/m2;Blade:40-60g/m2
Razor Thickness: 0.45±0.05mm Razor Barb Length: 22±1mm
Razor Barb Spacing: 34±1mm Barb Distance: 7.5-15cm
Certification: ISO9001:2015 Place Of Origin: Hebei Province,China
Packing: Waterproof Paper +Woven Bags Usage: Protecting Buliding;Grass Boundary,Railway
Sample: For Free Brand Name: Yuanhai
High Light:

bto-22 razor coil barbed wire

,

pvc coated razor coil barbed wire

,

500mm diameter razor barbed wire



BTO-22 PVC Coated Razor Barbed Wire 500mm Coil Diameter For Private House




Product Description of Razor Barbed Wire


Type: BTO-10,BTO-12,BTO-15,BTO-18,BTO-22,BTO-30,CBT-60,CBT-65 etc

Outside 450mm,500mm,700mm,600mm,980mm,1000mm etc as customers request

Material:

Electro galvanized core wire and blade;

Hot-dipped galvanized core wire and blade;

Stainess steel core wire and blade;

PVC coated core wire and blade;

hot-dipped galvanized core wire+stainless steel blade.

Razor type:single type,cross type(3 or 5clips per circle).

Razor Barbed Wire is also named concertina razor wire, razor fencing wire, razor blade wire or dannert wire. It is a kind of modern security fencing materials with better protection and fencing strength made of hot-dipped galvanized steel sheets or stainless steel sheets. With sharp blades and strong core wire, razor wire has the features of secure fencing, easy installation, age resistance and other properties.



Blade Style of Razor Barbed Wire

Specification



Reference Number Thickness Wire Dia Barb
Length
Barb
Width
Barb
spacing
BTO-10 0.5±0.05 2.5±0.1 10±1 13±1 25±1
BTO-12 0.5±0.05 2.5±0.1 12±1 15±1 25±1
BTO-18 0.5±0.05 2.5±0.1 18±1 15±1 35±1
BTO-22 0.5±0.05 2.5±0.1 22±1 15±1 36±1
BTO-28 0.5±0.05 2.5 28 15 46±1
BTO-30 0.5±0.05 2.5 30 18 46±1
CBT-65 0.6±0.05 2.5±0.1 65±2 21±1 101±1



Outside Diameter
No.of Loops

Standard Length per Coil
Type
Notes
450 mm
33



8m
CBT-65
Single coil
500 mm
41
10m
CBT-65
Single coil
700 mm
41
10m
CBT-65
Single coil
960 mm
53
13m
CBT-65
Single coil
500 mm
102
16m
BTO-10.15.22
Cross type
600 mm
86
14m
BTO-10.15.22
Cross type
700 mm
72
12m
BTO-10.15.22
Cross type
800 mm
64
10m
BTO-10.15.22
Cross type
960 mm
52
9m
BTO-10.15.22
Cross type



Advantages of Razor Barbed Wire



It is almost impossible to climb.

High-strength steel core very difficult to cut off.

Powerful security fence barriers neat appearance.

No secondary use, so he will not be stolen.

Extremely simple to install, needs three to four to install molding.

compromising perimeter security.


Packing and Shipping of Razor Barbed Wire



1. Each roll with inner waterproof paper and woven bag outside, then 50rolls or 100roll be a bundle by metal strip.

2. Be bundled razor wire put on pallet.
3. Bulk razor wire put into cartons.
4. Packaged razor wire barrier into wooden case.
5. Bulk waterproof paper inner with woven bag outside razor rolls loaded in 40'HQ/27tons


Application of Razor Barbed Wire



Widely used in military field, prisons, detention houses, government buildings and other national security facilities. Also fencing of residences, villa wall and windows, express way, railway, national border lines, etc.

Barbed wire is also widely used in various aspects of agriculture and life. Recently, barbed wire is used in rock planting. On the rock slope, the new technology of holding wire mesh and spraying powder and planting grass is adopted to achieve slope protection and at the same time play the effect of beautifying the environment.


Bto-22 Razor Coil Barbed Wire Pvc Coated 500mm Diameter For Private House 0



Bto-22 Razor Coil Barbed Wire Pvc Coated 500mm Diameter For Private House 1



Bto-22 Razor Coil Barbed Wire Pvc Coated 500mm Diameter For Private House 2



Bto-22 Razor Coil Barbed Wire Pvc Coated 500mm Diameter For Private House 3



Bto-22 Razor Coil Barbed Wire Pvc Coated 500mm Diameter For Private House 4



Packing & Delivery of Razor Barbed Wire


Bto-22 Razor Coil Barbed Wire Pvc Coated 500mm Diameter For Private House 5



Application of Razor Barbed Wire



Bto-22 Razor Coil Barbed Wire Pvc Coated 500mm Diameter For Private House 6


We use 3 common packages or as customer's request.

Bto-22 Razor Coil Barbed Wire Pvc Coated 500mm Diameter For Private House 7

Company Profile

1. Is your company a manufacturer or a trading company?
We are a manufacturer located in Anping County, China.
2. Do you have inport-export right?
Yes, we do. Our factory has been certificated as an import-export enterprise.
3. What is your payment mode?
30% in advance and 70% before delivery by T/T, WESTERN UNION, L/C or negotiated.
4. How about your packing?
We usually packed in plastic material inside and then wooden box outside.
5. How long is your delivery?
Usually 10-20 days after order confirmed, according the quantity ordered.
6. Is it sample available?
Yes, small pieces of sample are available in our company.
