Bto-22 Y Pillar Razor Barbed Wire Galvanized Concertina Airport / Prison 10kg Per Coil

China Anping yuanhai wire mesh products Co., Ltd certification
China Anping yuanhai wire mesh products Co., Ltd certification
Thanks for your kindly hospitality. Your company is very professional , we are very satisfied with your expanded metel sheet, we will have nice cooperation in the near future.

—— Roger Hopkins

Good company with nice service and high quality and high reputation. The stainless steel wire mesh is good quality,one of our reliable supplier , goods are delivered in time and nice package.

—— Mr.mosharaf hossain

Received ur Gabion Mesh,Thanks for your good after-sale service. Excellent training and technology support helps me a lot.

—— Tshediso Sedie

I'm Online Chat Now

Bto-22 Y Pillar Razor Barbed Wire Galvanized Concertina Airport / Prison 10kg Per Coil

Bto-22 Y Pillar Razor Barbed Wire Galvanized Concertina Airport / Prison 10kg Per Coil
Bto-22 Y Pillar Razor Barbed Wire Galvanized Concertina Airport / Prison 10kg Per Coil Bto-22 Y Pillar Razor Barbed Wire Galvanized Concertina Airport / Prison 10kg Per Coil

Large Image :  Bto-22 Y Pillar Razor Barbed Wire Galvanized Concertina Airport / Prison 10kg Per Coil

Product Details:
Place of Origin: AnPing,China
Brand Name: YuanHai
Certification: ISO 9001
Model Number: YH005
Payment & Shipping Terms:
Minimum Order Quantity: 200rolls
Price: Negotiable
Packaging Details: Waterproof paper or as customer's request
Delivery Time: 3-10days
Payment Terms: T/T
Supply Ability: 20000 Roll/Rolls per Month
Detailed Product Description
Material: Iron Wire, Low Carbon Steel Q195 Blade Type: CBT--65;BTO-22;BTO-28;BTO-30;
Surface Treatment: Galvanized/PVC Coated Zinc Coated: Galvanized Wire:8-60g/m2;Blade:40-60g/m2
Razor Thickness: 0.45±0.05mm Razor Barb Length: 22±1mm
Razor Barb Spacing: 34±1mm Usage: Protecting Buliding;Grass Boundary,Railway,Highway,Army Etc
Certification: ISO9001:2015 Place Of Origin: Hebei Province,China
Loop Number: 33-102 Coil Diameter: 450-900mm
Coil Weight: 10kg Coil Meter: 10m
High Light:

y pillar razor barbed wire

,

airport galvanized razor barbed wire

,

10kg barbed wire and razor wire

BTO-22 Y Pillar Galvanized Concertina Razor Wire For Airport / Prison 10KG Per Coil




Product Description of Razor Barbed Wire


When you need to get serious about security, Concertina razor Wire is the best solution. It is relatively inexpensive, but viciously effective. Concertina razor Wire around the perimeter is enough to deter any wouldbe vandal, robber or saboteur. Razor Wire is made of a corrosion resistant galvanized steel cutting ribbon wrapped around a core of galvanized spring steel wire. It's impossible to cut without highly specialized tools, and even then it's a slow, dangerous job. Concertina Razor Wire is a long lasting and very effective barrier, known and trusted by security professionals.


1. Material: Hot Dipped Galvanized sheet Hot Dipped Galvanized Wire / ElectroGalvanized sheet Hot Dipped Galvanized Wire
2. Core Wire Diameter: 2.7±0.1mm / 2.5±0.1mm
Razor Barbed sheet thickness: 0.45±0.05mm
3. Razor Loop Diameter: 600mm
Other Coil diameter for u choose: 300mm, 400mm, 450mm, 500mm, 600mm, 700mm, 800mm, 900mm, 1000mm.
450mm(3 clips), 500mm(3 clips), 600mm(3 clips)900mm(5 clips) are the usually sizes
4. Razor Barbed Wire per coil weight: Be produced as customers requirements. (common weight is 7KG 10KG, 12kg, 14kg)



Product Introduction of Razor Barbed Wire

  • Razor wire coils, helical or concertina available in galvanized steel or SS grades
  • Razor wire is also named concertina coils or razor type barbed wire
  • It is a kind of modern security fencing materials with better protection and fencing strength made of hot-dip galvanized steel sheets or stainless steel sheets
  • With beautiful and sharp blades and strong core wire, razor wire has the features of secure fencing, easy installation, age resistance and other properties
  • Razor type barbed wire is widely used in high-grade residence district, warehouses, prisons and in military fields and other sites requiring severe fencing and security
  • Razor wire can be classified into straight type razor wire, concertina coils, crossed type and flat type according to the installation models.

Blade Style of Razor Barbed Wire

Specification



Reference Number Thickness Wire Dia Barb
Length
Barb
Width
Barb
spacing
BTO-10 0.5±0.05 2.5±0.1 10±1 13±1 25±1
BTO-12 0.5±0.05 2.5±0.1 12±1 15±1 25±1
BTO-18 0.5±0.05 2.5±0.1 18±1 15±1 35±1
BTO-22 0.5±0.05 2.5±0.1 22±1 15±1 36±1
BTO-28 0.5±0.05 2.5 28 15 46±1
BTO-30 0.5±0.05 2.5 30 18 46±1
CBT-65 0.6±0.05 2.5±0.1 65±2 21±1 101±1



Outside Diameter
No.of Loops

Standard Length per Coil
Type
Notes
450 mm
33



8m
CBT-65
Single coil
500 mm
41
10m
CBT-65
Single coil
700 mm
41
10m
CBT-65
Single coil
960 mm
53
13m
CBT-65
Single coil
500 mm
102
16m
BTO-10.15.22
Cross type
600 mm
86
14m
BTO-10.15.22
Cross type
700 mm
72
12m
BTO-10.15.22
Cross type
800 mm
64
10m
BTO-10.15.22
Cross type
960 mm
52
9m
BTO-10.15.22
Cross type



Advantages of Razor Barbed Wire



It is almost impossible to climb.

High-strength steel core very difficult to cut off.

Powerful security fence barriers neat appearance.

No secondary use, so he will not be stolen.

Extremely simple to install, needs three to four to install molding.


Packing and Shipping of Razor Barbed Wire



1. Each roll with inner waterproof paper and woven bag outside, then 50rolls or 100roll be a bundle by metal strip.

2. Be bundled razor wire put on pallet.
3. Bulk razor wire put into cartons.
4. Packaged razor wire barrier into wooden case.
5. Bulk waterproof paper inner with woven bag outside razor rolls loaded in 40'HQ/27tons


Application of Razor Barbed Wire



Once invented in history, barbed wire has been widely used in military and defense projects; now in the peaceful era, barbed wire is alternately used in machinery, electronics, pharmaceuticals, petrochemicals, glass, food drying, plastics, paper, chemical fiber, picture tubes and other industries.
Barbed wire is also widely used in various aspects of agriculture and life. Recently, barbed wire is used in rock planting. On the rock slope, the new technology of holding wire mesh and spraying powder and planting grass is adopted to achieve slope protection and at the same time play the effect of beautifying the environment.



Bto-22 Y Pillar Razor Barbed Wire Galvanized Concertina Airport / Prison 10kg Per Coil 0



Bto-22 Y Pillar Razor Barbed Wire Galvanized Concertina Airport / Prison 10kg Per Coil 1



Bto-22 Y Pillar Razor Barbed Wire Galvanized Concertina Airport / Prison 10kg Per Coil 2



Bto-22 Y Pillar Razor Barbed Wire Galvanized Concertina Airport / Prison 10kg Per Coil 3



Bto-22 Y Pillar Razor Barbed Wire Galvanized Concertina Airport / Prison 10kg Per Coil 4




Packing & Delivery of Razor Barbed Wire


Bto-22 Y Pillar Razor Barbed Wire Galvanized Concertina Airport / Prison 10kg Per Coil 5

We use 3 common packages or as customer's request.

Bto-22 Y Pillar Razor Barbed Wire Galvanized Concertina Airport / Prison 10kg Per Coil 6



Company Profile

1. Is your company a manufacturer or a trading company?
We are a manufacturer located in Anping County, China.
2. Do you have inport-export right?
Yes, we do. Our factory has been certificated as an import-export enterprise.
3. What is your payment mode?
30% in advance and 70% before delivery by T/T, WESTERN UNION, L/C or negotiated.
4. How about your packing?
We usually packed in plastic material inside and then wooden box outside.
5. How long is your delivery?
Usually 10-20 days after order confirmed, according the quantity ordered.
6. Is it sample available?
Yes, small pieces of sample are available in our company.
