Product Details:
Payment & Shipping Terms:
|
| Material: | Low Carbon Steel Wire | Hole Size: | 3"x0.5" / 76.2*12.7mm |
|---|---|---|---|
| Wire Diameter: | 4.0mm Or Customized | Post Size: | 60x60mm, 60x80mm, 80x80mm |
| Surface Treatment: | Galvanized,powder Coated,PVC Coated | Fence Topping: | Razor Wire, Barbed Wire, Anti Climb Spikes |
| Fence Height: | 3.0m, 2.4m, 2.2m, 2.0m Or Customized | Brand Name: | YH |
| Welded Strength: | Range 540–690 N/m2. | Color: | Green RAL 6005/Black RAL 9005. |
| Application: | Residential, School, Outdoor,Garden Fence | Post Distance: | 2000mm, 2500mm, 3000mm |
| Sample: | For Free | Place Of Origin: | Hebei Province,China |
| High Light: | welded wire mesh 358 security fencing,anticlimb antitheft 358 security fencing,76.2*12.7mm galvanized anti climb fence |
||
Clear View Welded Wire Mesh Fence 358 Anti Climb / Theft Fence 76.2*12.7mm
Description of 358 Security Fencing
Why is it called 358 Security Fence? '358' comes from its measurements 3" × 0.5" × 8 gauges which equates to approx. 76.2mm × 12.7mm × 4mm (Length × height × Diameter) in metric.
358 security fences are extremely difficult to penetrate, with the small mesh aperture being effectively finger proof, and extremely difficult to attack using conventional hand tools. 358 fences are recognized as one of the most difficult to break through the barrier, because it is difficult to climb. It is called security fencing and high- strength fencing. 358 security fencing panel can be bent in part to enhance the aesthetic effect.
While 3510 Security Fencing has many of the attributes of 358 Security Fencing and its main strength is it's lighter. Using 3mm wire instead of 4mm allows even better visibility allowing a wider variety of applications. It’s lighter and cheaper so it's ideal for commercial applications.
Specifications of 358 Security Fencing
| Specification of 358 Security Fencing | |||||
| Mesh Opening | Wire Diameter | Panel Height | Panel Width | Post Type | |
| 12.7x76.2mm (0.5'' x 3'') |
3/3.5/4mm | 1.2-6m | 2.0-3.1m | Square Post(SHS) 60x60x2.0/2.5/3.0mm 80x80x2.0/2.5/3.0mm |
Rectangular Post(RHS) 40x60x2.0/2.5/3.0mm 40x80x2.0/2.5/3.0mm 60x80x2.0/2.5/3.0mm 80x100x2.0/2.5/3.0mm |
| Surface treatment:hot dipped galvanized, galvanized +powder coated, galvanized +PVC coating. | |||||
| Color:RAL 6005 green, RAL 7016 gray, All RAL color can be customized. | |||||
| Note:The fence can be customized according to your required if above specification is not satisfied with you. | |||||
| 358 fence | 2.1m | 2.4m | 3.0m |
| 358 fence hight | 2134mm | 2438mm | 2997mm |
| 358 fence width | 2515mm | 2515mm | 2515mm |
| 358 fence hole size | 12.7*76.2mm | 12.7*76.2mm | 12.7*76.2mm |
| wire | 4mm | 4mm | 4mm |
| wire | if need other wire diameter can order | ||
| 358 fence posts | 60*60*3mm | 60*60*3mm | 60*60*3mm |
| 358 fence posts length | 2.8m | 3.1m | 4.0m |
| no of fixings | 8 | 9 | 11 |
Features of 358 Security Fencing
1.Anti-climbing - Due to the high-density mesh of the 358 guardrail, it is impossible to grasp the hands and feet, which plays a very good protection against climbing.
2.Anti-shear - the wire diameter is large, the mesh is dense, making the wire cut useless.
3.Beautiful appearance - the mesh surface is flat, and the perspective is higher.
Surface treatment of 358 Security Fencing
1> Electric Galvanized Then PVC Coated(powder thickness 0.1mm)
2>Electric Galvanized Then Powder Coated(powder thickness 0.8-1.2mm)
3>Hot Dipped Galvanized Then PVC Coated(powder thickness 0.1mm)
4>Hot Dipped Galvanized Then Powder Coated(powder thickness 0.8-1.2mm)
5>Hot Dipped Galvanized After Welded(zinc coating: 40-500g/m²)
Application of 358 Security Fencing
