Pvc Coated Green Steel Palisade Fencing Europe 2.4mm Pale For Railway

Pvc Coated Green Steel Palisade Fencing Europe 2.4mm Pale For Railway
Pvc Coated Green Steel Palisade Fencing Europe 2.4mm Pale For Railway Pvc Coated Green Steel Palisade Fencing Europe 2.4mm Pale For Railway

Large Image :  Pvc Coated Green Steel Palisade Fencing Europe 2.4mm Pale For Railway

Product Details:
Place of Origin: CHINA
Brand Name: YUANHAI
Certification: ISO9001
Model Number: YH-PF
Payment & Shipping Terms:
Minimum Order Quantity: 10 Sets
Price: Negotiable
Packaging Details: Powder Coated Frame Finishing And Fencing Trellis & Gates Type Palisade Fence Water Proof Paper+Pallet.Custom Packaging Is Also Available According To Your Details
Supply Ability: 5000Sets Per Month
Detailed Product Description
Product Name: Steel Palisade Fencing Key Word: Palisade Fencing
Material: Mid Steel Fence Panel Height: 1-6m
Fence Panel Width: 1-3m Pale Types: W Pale / D Pale
W Pale Width: 65-75mm D Pale Width: 65-70mm
Angle Rail: 40mmx40mm 50mmx50mm 63mmx63mm Angle Rail Thickness: 3mm-6mm
Surface Treatment: Galvanized/PVC Coated Feature: Easily Assembled, Sustainable, Rodent Proof
Certification: ISO9001:2015 Port Of Loading: Tianjin Xingang Port
MOQ: Accepted Sample: For Free
Brand Name: YuanHai
High Light:

pvc coated green steel palisade fencing

,

2.4mm pale steel palisade fencing

,

railway metal palisade fencing

PVC Coated Green Steel Palisade Europe Fence 2.4mm Pale For Railway





Description of Steel Palisade Fencing



W pale Palisade fence (straight type) is the most popular choice for the high security fence. By now, we have shipped the palisade fence to Europe, Middle east, Africa as well as Australia. It used as private fence or public fence, specially for high security purpose.



Steel Palisade Fence Detail

  • Palisade fence: One pointed, triple pointed, rounded, rounded & notched and square top.
  • Palisade gate: Singular leaf or double leaf, swing or sliding gate, cantilever gate.
  • Steel palisade fence: Made of low carbon steel, mild steel, hot or cold rolled steel.
  • Galvanized palisade fence: Palisade fence or palisade gate can be finished with hot-dipped or electric galvanized.
  • Palisade pales: The pales can be W section, D section and angle section.
  • Palisade post: The palisade posts have square type and RSJ beam type.
  • Palisade rail: Angle type with slots to fix.
  • Palisade fittings: Connecting parts include fishplates, post clamps, bolts and nuts.

Specifications of Steel Palisade Fence



Fence panel height
1m-6m
Fence panel width
1m-3m
Pale height
0.5m-6m
Pale width
W pale 65-75mm d pale 65-70mm
Pale thickness
1.5-3.0mm
Angle rail
40mmx40mm 50mmx50mm 63mmx63mm
Angle rail thickness
3mm-6mm
RSJ post
100mmx55mm 100mmx68mm 150mmx75mm
Square post
50mmx50mm 60mmx60mm 75mmx75mm 80mmx80mm
Square post thickness
1.5mm-4.0mm
Straight fishplates or post clamps
30mmx150mmx7mm 40mmx180mmx7mm
Bolts and nuts
M8XNo.34 for pale fixing M12xNo.4 for rail fixing



Package of Steel Palisade Fence



1. LCL: first packed with plastic film then on the pallets
2. FCL: Nude packing
3.other special package according to customers' requirements



Features of Steel Palisade Fence

  • The palisade fence made of steel has good strength, high rigidity, with high damage and intrude resistance, so it can provide highest security.
  • The surface treatment makes the palisade fence own high rust and corrosion resistance, so it will have longer service life.
  • Palisade fence after galvanized, PVC or powder coated will become more smooth, need not maintain frequently and is easy to become a brand-new fence.
  • The palisade fence is easy to install and remove, so it is simple to replace the old or broken one.
  • The style of palisade fence is beautiful and generous, it can decorate the place that you live and work. Further more, it won't block your sight.
  • The price is competitive, so palisade fence is a cost-effective fence to provide the highest security for you.

Applications of Steel Palisade Fence



Galvanized palisade fence with beautiful appearance and eco-friendly advantages can be widely used in industrial areas, airports, railways and schools.





                                                  Head Types of W&D Section Pales



Pvc Coated Green Steel Palisade Fencing Europe 2.4mm Pale For Railway 0





Pvc Coated Green Steel Palisade Fencing Europe 2.4mm Pale For Railway 1





Pvc Coated Green Steel Palisade Fencing Europe 2.4mm Pale For Railway 2



Pvc Coated Green Steel Palisade Fencing Europe 2.4mm Pale For Railway 3



Pvc Coated Green Steel Palisade Fencing Europe 2.4mm Pale For Railway 4



Pvc Coated Green Steel Palisade Fencing Europe 2.4mm Pale For Railway 5



Pvc Coated Green Steel Palisade Fencing Europe 2.4mm Pale For Railway 6



Pvc Coated Green Steel Palisade Fencing Europe 2.4mm Pale For Railway 7
