1230mm 3D Curved Triangle Fence Panel BRC Mesh Fencing For School rustproof

China Anping yuanhai wire mesh products Co., Ltd certification
China Anping yuanhai wire mesh products Co., Ltd certification
Thanks for your kindly hospitality. Your company is very professional , we are very satisfied with your expanded metel sheet, we will have nice cooperation in the near future.

—— Roger Hopkins

Good company with nice service and high quality and high reputation. The stainless steel wire mesh is good quality,one of our reliable supplier , goods are delivered in time and nice package.

—— Mr.mosharaf hossain

Received ur Gabion Mesh,Thanks for your good after-sale service. Excellent training and technology support helps me a lot.

—— Tshediso Sedie

I'm Online Chat Now

1230mm 3D Curved Triangle Fence Panel BRC Mesh Fencing For School rustproof

1230mm 3D Curved Triangle Fence Panel BRC Mesh Fencing For School rustproof
1230mm 3D Curved Triangle Fence Panel BRC Mesh Fencing For School rustproof 1230mm 3D Curved Triangle Fence Panel BRC Mesh Fencing For School rustproof

Large Image :  1230mm 3D Curved Triangle Fence Panel BRC Mesh Fencing For School rustproof

Product Details:
Place of Origin: CHINA
Brand Name: YUANHAI
Certification: ISO9001
Model Number: YH-DF
Payment & Shipping Terms:
Minimum Order Quantity: 50 PCS
Price: Negotiable
Packaging Details: Pallet
Supply Ability: 5000PCS PER MONTH
Detailed Product Description
Material: Low Carbon Steel Wire Diameter: 3.5mm-5.0mm
Mesh Size: 50*200mm 55*200mm 50*150mm 55*100mm Surface Treatment: Galvanized+PVC Coated
Height: 1030mm/1230mm/1530mm/1830mm Or As Request Length: 2000mm/2200mm/2500mm/3000mm
Advantage: Anti-corrosion Post Shape: Round Posts, Square Posts, Peach Posts
Packing: In Pallet, Plastic Film In Outside Application: Airports, Ports, Terminals Security
Product Name: Triangle Fence Panel Port Of Loading: Xingang Port
Sample: Provide Customized: Accept
High Light:

1230mm Triangle Fence Panel

,

1230mm BRC Mesh Fencing

,

Triangle Fence Panel Rustproof

Galvanized 3D Curved Triangle BRC Mesh Fencing 50*200mm For School


Product Description of Triangle Bending Wire Mesh Fence Panel

The triangular bending fence mesh adopts excellent grade Q 235 low carbon cold drawn steel wire, cold drawn low carbon steel wire and low carbon steel wire as raw materials. And carry out the corresponding anti-corrosion treatment: electro galvanized, hot-dip galvanizing, spray-spraying, dip-coating and stainless steel wire (usually using dip-coating treatment). Features of Triangle Bend Fence Net: Weaving and welding are bent. Commonly used peach-shaped column connection is also called peach-shaped column fence.

Triangle bending fence mesh Common specifications: Dip wire diameter: 4.0-6.0mm Grid size: 50mm x180mm 60mmx200mm Peach type column size: 50x70mm 70x100mm thickness 1-2mm mesh size: 2.5mx3.0m Reinforcement: three bends Or four bends: Structure: After welding with high-strength cold-drawn wire and low-carbon steel wire, it is hydroformed and fixed with a link attachment and steel pipe struts.



Panel Specification of Triangle Bending Wire Mesh Fence Panel



Panel height
Panel Length
Wire Diameter
Mesh Size
Folds No.
0.6/0.63m







2.5m or custom



Gal + Powder Coated
3.85mm/4.0mm
4.85mm/5.0mm

Gal + PVC Coated
3.0mm/4.0mm
4.0mm/5.0mm

Hot-dipped Gal.






50*200mm
55*200mm
50*150mm
55*100mm
2
1.0/1.03m
2
1.2/1.23m
2
1.5/1.53m
3
1.7/1.73m
3
1.8/1.83m
3/4
1.9/1.93m
3
2.0/2.03m
4
2.4/2.43m
4


Surface treatment:hot dipped galvanized, galvanized +powder coated, galvanized +PVC coated
Color: RAL 6005 green, RAL 7016 gray, RAL 9005 black,All RAL color can be customized.
Note: The fence can be customized according to your required if above specification is not satisfied with you.


Advantage of Triangle Bending Wire Mesh Fence Panel

Appropriate bending makes the unique aesthetic effect of this product, and the surface is treated with dip coating of various colors, such as yellow, green, red, and the color of the column and the mesh is different. It is pleasing to the eye, and at the same time, this kind of product is mostly equipped with a chassis column, and the installation only needs to lay the expansion bolts, which is very fast.

Application of Triangle Bending Wire Mesh Fence Panel

Triangle bending protection net has been widely used in the decorative protection of highways, highways, railways, airports, factories, factories, residential quarters, port terminals, municipal green spaces, garden flower beds and green spaces. The triangular bending fence mesh has high strength, good rigidity, beautiful appearance, wide field of vision, easy installation, and feels bright and easy.

Production Process of Triangle Bending Wire Mesh Fence Panel

Wire Drawing → Wire Straightening & Wire Cutting → Welding → Folds/Curves Bending → Electric Galvanizing/Hot-dipped Galvanizing → Parkerizing → PVC Coating /Spraying → Packing → Loading

PVC Coating Colors of Triangle Bending Wire Mesh Fence Panel

1230mm 3D Curved Triangle Fence Panel BRC Mesh Fencing For School rustproof 0



1230mm 3D Curved Triangle Fence Panel BRC Mesh Fencing For School rustproof 1



1230mm 3D Curved Triangle Fence Panel BRC Mesh Fencing For School rustproof 2

1230mm 3D Curved Triangle Fence Panel BRC Mesh Fencing For School rustproof 3

Packing of Triangle Bending Wire Mesh Fence Panel



1230mm 3D Curved Triangle Fence Panel BRC Mesh Fencing For School rustproof 4



1230mm 3D Curved Triangle Fence Panel BRC Mesh Fencing For School rustproof 5

1230mm 3D Curved Triangle Fence Panel BRC Mesh Fencing For School rustproof 6
