Q235 Hot Dipped Galvanised Walkway Grating 32*3mm Stair Tread Grating

Q235 Hot Dipped Galvanised Walkway Grating 32*3mm Stair Tread Grating
Q235 Hot Dipped Galvanised Walkway Grating 32*3mm Stair Tread Grating Q235 Hot Dipped Galvanised Walkway Grating 32*3mm Stair Tread Grating

Large Image :  Q235 Hot Dipped Galvanised Walkway Grating 32*3mm Stair Tread Grating

Product Details:
Place of Origin: CHINA
Brand Name: YUANHAI
Certification: ISO9001
Model Number: YH-G1
Payment & Shipping Terms:
Minimum Order Quantity: 1000Square Meters
Price: Negotiable
Packaging Details: 1.normally packed in pilling up ways with two pieces of square wood on both upperand bottom sides. 2.acccording to customer's requirements.
Supply Ability: 100000Square Meters Per Month
Detailed Product Description
Material: Low Carbon Steel, Stainless Steel Thickness: 0.3-0.8mm
Shape: Square / Rectangular Surface Treatment: Hot Dipped Galvanized
Usage: Platform , Driveway, Industry Platform ,building Product Name: Galvanized 32*5mm Steel Walkway Grating
Type: Flat Steel Bar ,serrated Steel Bar Certificate: ISO9001:2015
Sizes: Customized Package: By Steel Pallet
Highlight:

Q235 galvanised walkway grating

,

Galvanised Walkway Grating 32mm

,

3mm Stair Tread Grating

Q235 Galvanized Steel Walkway Grating 32*3mm For Stair Treads / Walkway





Description of Steel Grating Walkway



Steel grating/Bar grating are welded by flat bar and square twist bar, or fully welded by flat bar. It can be used for a variety of applications. Bar grating is an ideal choice for projects ranging from trenches and stair treads to decking and steel flooring. Used as metal grates, bar grating covers open areas in flooring that require light, liquid, air, heat, and sound to pass between flooring levels.



Materials: mild steel or stainless steel.

Surface treatment: untreated, painting or hot dip galvanizing.

Bearing bar specification:20*3 to 100*6

Bearing bar pitch:12.5,15,25,30,40,60mm etc. also be according to clients requirement and 30,40,60mm are recommended

Cross bar picth:38,50,76,100mm,also be according to clients requiremen and 50,100mm are recommended.

The Maximun length of black panel is 7350mm.



Advantage of Steel Grating Walkway

  • Light weight
  • great load-bearing capacity
  • non-slip and e
  • easy installation
  • material-economic
  • sturdy and durable
  • ventilated, easy to clean and attractive appearance.

Surface Treatment of Steel Grating Walkway


Steel grating panel can choose galvanized,
stainless steel grating can choose polishing etc.



Specifications of Steel Grating Walkway



The steel bar size and specification ,please check the following table:



Specification of galvanized steel grating

steel walkway and floor Steel grid plate and Steel frame lattice in metal building materials

Type Welded steel grating, pressure locked, socket welding
Material Low carbon steel, stainless steel, aluminum
Bearing bar 20x5, 25x3, 25x4, 25x5, 30x3, 30x4, 30x5, 32x3, 32x5, 40x5, 50…75x8mm, etc.
Bearing bar pitch(center to center) 25, 30, 30.16, 32.5, 34.3, 40, 50, 60, 62, 65mm, etc.or accord to the client’s request
Cross bar 5x5, 6x6, 8x8mm (twisted bar or round bar)
Cross bar pitch 40, 50, 60, 65, 76, 100, 101.6, 120, 130mm or as customers’ requirement.
Flat bar type Plain, Serrated (tooth-like),


Application of Steel Grating Walkway



Steel grating has been widely used in all walks of life both at home and abroad, mainly used for industrial platform, staircase pedal, banister, channel floor ,railway bridge service, high tower platform, the drain cover, manhole covers, road barrier ,three-dimensional parking lot, organs, schools, factories, enterprises and institutions, the stadium fence, garden villa, also can be used as a residence outside the window, balcony guardrail, highway ,rail barrier ,etc.



Q235 Hot Dipped Galvanised Walkway Grating 32*3mm Stair Tread Grating 0



Q235 Hot Dipped Galvanised Walkway Grating 32*3mm Stair Tread Grating 1



Q235 Hot Dipped Galvanised Walkway Grating 32*3mm Stair Tread Grating 2



Q235 Hot Dipped Galvanised Walkway Grating 32*3mm Stair Tread Grating 3



Q235 Hot Dipped Galvanised Walkway Grating 32*3mm Stair Tread Grating 4
