Galvanized Metal Catwalk Flooring Steel Walkway Grating For Chemical Plant 25*5mm

China Anping yuanhai wire mesh products Co., Ltd certification
China Anping yuanhai wire mesh products Co., Ltd certification
Thanks for your kindly hospitality. Your company is very professional , we are very satisfied with your expanded metel sheet, we will have nice cooperation in the near future.

—— Roger Hopkins

Good company with nice service and high quality and high reputation. The stainless steel wire mesh is good quality,one of our reliable supplier , goods are delivered in time and nice package.

—— Mr.mosharaf hossain

Received ur Gabion Mesh,Thanks for your good after-sale service. Excellent training and technology support helps me a lot.

—— Tshediso Sedie

I'm Online Chat Now

Galvanized Metal Catwalk Flooring Steel Walkway Grating For Chemical Plant 25*5mm

Galvanized Metal Catwalk Flooring Steel Walkway Grating For Chemical Plant 25*5mm
Galvanized Metal Catwalk Flooring Steel Walkway Grating For Chemical Plant 25*5mm Galvanized Metal Catwalk Flooring Steel Walkway Grating For Chemical Plant 25*5mm

Large Image :  Galvanized Metal Catwalk Flooring Steel Walkway Grating For Chemical Plant 25*5mm

Product Details:
Place of Origin: CHINA
Brand Name: YUANHAI
Certification: ISO9001
Model Number: YH-G1
Payment & Shipping Terms:
Minimum Order Quantity: 1000Square Meters
Price: Negotiable
Packaging Details: 1.normally packed in pilling up ways with two pieces of square wood on both upperand bottom sides. 2.acccording to customer's requirements.
Supply Ability: 100000Square Meters Per Month
Detailed Product Description
Material: Low Carbon Steel, Stainless Steel Thickness: 0.3-0.8mm
Shape: Square / Rectangular Surface Treatment: Hot Dipped Galvanized
Usage: Platform , Driveway, Industry Platform ,building Product Name: Steel Walkway Grating
Type: Flat Steel Bar ,serrated Steel Bar Certificate: ISO9001:2015
Sizes: Customized Package: By Steel Pallet
Brand Name: Yuanhai Place Of Origin: Hebei,Province
Bearing Bar Type: Serrated/teeth Plain/smooth I Bar Serrated I Bar HS Code: 73089000
Highlight:

Chemical Plant metal catwalk flooring

,

Chemical Plant Steel Walkway Grating

,

metal catwalk flooring 5mm

Galvanized Catwalk Floor Steel Walkway Grating For Chemical Plant 25*5mm





Description of Steel Grating Walkway



The compound steel grating is a perfect combination of steel bar grating and checkered plate, featuring beautiful appearance and high solidity. When it comes to the manufacture of compound steel bar grating, 3G323/40/100, 3G253/30/100 and 3G323/40/100 steel bar grating are most often used as the base plate. Then, weld 3mm thick checkered plate upon the steel grating panel. The checker plate thickness also can be 4mm, 5mm. After proper polishing and hot dipped galvanized surface treatment, a good condition compound steel bar grating is produced. In consideration of different working conditions, the dimensions and materials of steel grating and checkered plate can be customized. We can produce carbon steel, stainless steel compound steel grating.



Materials: mild steel or stainless steel.

Surface treatment: untreated, painting or hot dip galvanizing.

Bearing bar specification:20*3 to 100*6

Bearing bar pitch:12.5,15,25,30,40,60mm etc. also be according to clients requirement and 30,40,60mm are recommended

Cross bar picth:38,50,76,100mm,also be according to clients requiremen and 50,100mm are recommended.

The Maximun length of black panel is 7350mm.



Specifications of Steel Grating Walkway



The steel bar size and specification ,please check the following table:



Specification of galvanized steel grating

steel walkway and floor Steel grid plate and Steel frame lattice in metal building materials

Type Welded steel grating, pressure locked, socket welding
Material Low carbon steel, stainless steel, aluminum
Bearing bar 20x5, 25x3, 25x4, 25x5, 30x3, 30x4, 30x5, 32x3, 32x5, 40x5, 50…75x8mm, etc.
Bearing bar pitch(center to center) 25, 30, 30.16, 32.5, 34.3, 40, 50, 60, 62, 65mm, etc.or accord to the client’s request
Cross bar 5x5, 6x6, 8x8mm (twisted bar or round bar)
Cross bar pitch 40, 50, 60, 65, 76, 100, 101.6, 120, 130mm or as customers’ requirement.
Flat bar type Plain, Serrated (tooth-like),


Advantage of Steel Grating Walkway



Steel grating has good strength, large carrying capacity and can save materials and cost. It offers good ventilation of light and wind, a modern sense, aesthetic appearance and anti-skid ety. It is also easy to clean, easy to installation and durable for uses.



Surface Treatment of Steel Grating Walkway


Steel grating panel can choose galvanized,
stainless steel grating can choose polishing etc.



Application of Steel Grating Walkway



Metallurgy, petroleum, shipbuilding, chemical industry, port, platform, joist, limb hand, pier and groove panel, pedal, sun shade, ventilation pervious to light, etc.



Galvanized Metal Catwalk Flooring Steel Walkway Grating For Chemical Plant 25*5mm 0



Galvanized Metal Catwalk Flooring Steel Walkway Grating For Chemical Plant 25*5mm 1



Galvanized Metal Catwalk Flooring Steel Walkway Grating For Chemical Plant 25*5mm 2



Galvanized Metal Catwalk Flooring Steel Walkway Grating For Chemical Plant 25*5mm 3



Galvanized Metal Catwalk Flooring Steel Walkway Grating For Chemical Plant 25*5mm 4
