Ss 304 / 316 Mesh Wire Filter Iso Certified Plain Dutch Weave

China Anping yuanhai wire mesh products Co., Ltd certification
China Anping yuanhai wire mesh products Co., Ltd certification
Thanks for your kindly hospitality. Your company is very professional , we are very satisfied with your expanded metel sheet, we will have nice cooperation in the near future.

—— Roger Hopkins

Good company with nice service and high quality and high reputation. The stainless steel wire mesh is good quality,one of our reliable supplier , goods are delivered in time and nice package.

—— Mr.mosharaf hossain

Received ur Gabion Mesh,Thanks for your good after-sale service. Excellent training and technology support helps me a lot.

—— Tshediso Sedie

I'm Online Chat Now

Ss 304 / 316 Mesh Wire Filter Iso Certified Plain Dutch Weave

Ss 304 / 316 Mesh Wire Filter Iso Certified Plain Dutch Weave
Ss 304 / 316 Mesh Wire Filter Iso Certified Plain Dutch Weave Ss 304 / 316 Mesh Wire Filter Iso Certified Plain Dutch Weave

Large Image :  Ss 304 / 316 Mesh Wire Filter Iso Certified Plain Dutch Weave

Product Details:
Place of Origin: Hebei Province,China
Brand Name: Yuanhai
Certification: ISO 9001:2015
Model Number: YH-008
Payment & Shipping Terms:
Minimum Order Quantity: 50 PCS
Price: Negotiation
Packaging Details: By pallet or as demand
Delivery Time: according to quantity
Payment Terms: TT/LC
Supply Ability: 10000PCS/10 DAYS
Detailed Product Description
Keyword: Stainless Steel Wire Mesh Application: Mining , Chemical Industry, Food Industry And Pharmaceutical Industry
Customized: Accept Port Of Loading: Xingang Port
Width: Up To 4000mm(Also Can Cut To 0.05—0.99m) Mesh Opening: 0.003 To 10mm
Wire Diameter: 0.010 To 1.20mm Brand Name: Yuanhai
High Light:

ss 304 mesh wire filter

,

plain dutch weave mesh wire filter

,

ss 316 stainless steel filtration mesh

Product Description:

Stainless Steel Wire Mesh Filter

Stainless Steel Wire Mesh Filter is made of premium stainless steel wire mesh which is woven in plain weave, twill weave, plain dutch weave and twill dutch weave. With its excellent rust resistance and acid and alkali resistance, the stainless steel mesh filter has a long service life and is widely used in mining, chemical industry, food industry and pharmaceutical industry.

The stainless steel micron filter cloth is available in both plain and twill weave and is ideal for filtration of particles ranging from 0.05mm to 999 microns. With high tensile strength and superior abrasion resistance, the wire mesh filter screen is highly durable and is available in a wide range of sizes up to 4000mm and can be customized to suit your needs.

Our stainless steel wire mesh is ISO9001:2015 certified and is guaranteed to provide the highest quality and service. It is also possible to customize the product according to your needs.

Type Mesh/Inch Wire diameter
(inch)
OPen Area Weight (LB)
/100 Square Foot
Plain,Twill Wire Mesh 1 × 1-635 × 635 0.0008"-0.08" 25 to 84.6 2.53 to 41.1
Type Mesh/Inch Wire diameter
(inch)
Absolute Filtration
Finess μm
Nominal Filtration
Finess μm
Plain Dutch Weave
Wire Mesh
8 × 85 - 80 × 400 0.014'' × 0.0126''- 0.0049'' × 0.0028'' 318-340 to 43-48 250-255 to 35-40
Twill Dutch Weave
Wire Mesh
20 × 250 - 500 × 3200 0.0098'' × 0.0079'' - 0.0015'' × 0.0010'' 110-120 to 8-9 98-105 to 2-

Features:

  • Product Name: Stainless Steel Wire Mesh Filter
  • Weaving Types: Plain Weave, Twilled Weave, Plain Dutch Weave, Twilled Dutch Weave
  • Certification: ISO9001:2015
  • Application: Mining, Chemical Industry, Food Industry And Pharmaceutical Industry
  • Price: Negotiation
  • Wire Diameter: 0.010 To 1.20mm
  • Keywords: Stainless Steel Wire Mesh Sieve, Stainless Steel Wire Mesh, Stainless Steel Woven Wire Mesh


Applications:

Yuanhai's stainless steel woven wire mesh filter, model YH-008, is made of high-grade 304/304L/316/316L stainless steel with a wire diameter ranging from 0.010 to 1.20mm. This filter is widely used in various industries, such as food, chemical and pharmaceutical, due to its excellent filtration performance. It is produced in Hebei Province, China and has obtained the ISO 9001:2015 certification. It is available in customized sizes and shapes. The minimum order quantity is 50 PCS and the price is negotiable. The delivery time and payment terms depend on the quantity. Delivery is usually by pallet and the supply ability is 10000 PCS/10 days.



Support and Services:

We provide technical support and services for Stainless Steel Wire Mesh Filter products. Our support team is available 24 hours a day, 7 days a week to answer any questions or provide guidance on installation and maintenance of the product. Our service team is also available to provide on-site installation and maintenance of the product. We guarantee the quality of the product and provide a warranty for any manufacturing defects.



Packing and Shipping:

Packaging and Shipping for Stainless Steel Wire Mesh Filter:

The product is shipped in strong, sealed cardboard boxes. Each box is filled with foam to ensure that the product arrives at its destination undamaged. To minimize the risk of breakage, the product is also wrapped in bubble wrap and secured with tape. We also offer shipping services for larger orders.



Ss 304 / 316 Mesh Wire Filter Iso Certified Plain Dutch Weave 0Ss 304 / 316 Mesh Wire Filter Iso Certified Plain Dutch Weave 1

Ss 304 / 316 Mesh Wire Filter Iso Certified Plain Dutch Weave 2

Ss 304 / 316 Mesh Wire Filter Iso Certified Plain Dutch Weave 3



Ss 304 / 316 Mesh Wire Filter Iso Certified Plain Dutch Weave 4

FAQ:

Q: What is the Brand Name of this product?
A: The Brand Name of this product is Yuanhai.
Q: What is the Model Number of this product?
A: The Model Number of this product is YH-008.
Q: What is the Place of Origin of this product?
A: The Place of Origin of this product is Hebei Province, China.
Q: Does this product have a Certification?
A: Yes, this product has a Certification of ISO 9001:2015.
Q: What is the Minimum Order Quantity of this product?
A: The Minimum Order Quantity of this product is 50 PCS.
