2.4m Galvanized PVC Coated Green Tubular Steel Fencing Palisade 65*2.5mm

Large Image : 2.4m Galvanized PVC Coated Green Tubular Steel Fencing Palisade 65*2.5mm

Product Details:

Place of Origin:	CHINA
Brand Name:	YUANHAI
Certification:	ISO9001
Model Number:	YH-PFW

Payment & Shipping Terms:

Minimum Order Quantity:	10Sets
Price:	$5.5-13.6/㎡
Packaging Details:	Powder Coated Frame Finishing And Fencing Trellis & Gates Type Palisade Fence Water Proof Paper+Pallet.Custom Packaging Is Also Available According To Your Details
Supply Ability:	5000Sets Per Month

Chat Now

Detailed Product Description

Product Name:	Steel Palisade Fencing	Key Word:	Security Fence
Material:	Pre Hot-dipped Galvanized Tube	Frame Material:	Metal
Frame Finishing:	Powder Coated	Feature:	Easily Assembled, Eco Friendly, Renewable Sources, Rodent Proof, Waterproof
Sample:	For Free	Suggested Pale Thickness:	2-6mm
Height Above Ground:	1-4.2m	Certification:	ISO9001:2015
Highlight:	Palisade Tubular Steel Fencing , 65*2.5mm Tubular Steel Fencing , 2.4m Tubular Steel Fencing

2.4m Galvanized PVC Coated Green Tubular Steel Fencing Palisade 65*2.5mm

Steel Palisade Fence Description

The palisade fence made of steel has good strength, high rigidity, with high damage and intrude resistance, so it can provide highest security.
The surface treatment makes the palisade fence own high rust and corrosion resistance, so it will have longer service life.
Palisade fence after galvanized, PVC or powder coated will become more smooth, need not maintain frequently and is easy to become a brand-new fence.
The palisade fence is easy to install and remove, so it is simple to replace the old or broken one.
The style of palisade fence is beautiful and generous, it can decorate the place that you live and work. Further more, it won't block your sight.
The price is competitive, so palisade fence is a cost-effective fence to provide the highest security for you.

Steel Palisade Fence Specification

Material: low carbon steel, mild steel, hot or cold rolled steel.
Finished: galvanized, powder coated, PVC coated.
Head type: one pointed, triple pointed, rounded, rounded & notched, square.
Pales section: D section pales, W section pales, angle section pales.
Height: 1.2 m up to 3.6 m.
Thickness: 1.5 mm - 4 mm.
Package: plastic film, wooden pallet.

1. Type Standard Configuration
Panel Height	Pales		O/C Spacing	Rails
8	13 ga.		5-15/16"	2" TS x 14 ga.
10	13 ga.		5-15/16"	2" TS x 14 ga.
12	13 ga.		5-15/16"	2" TS x 14 ga.
2. Type Standard Configuration
Post		Optionally available with base plates for bolt-down or cranked over walls. Also available with bracket extensions for barbed wire or razor wire. Size: 100 x 55mm/100 x 44mm
Rails		Steel angle rails punched for pale attachment. Connected with 12mm square cup bolts and anti-vandal permacone (snap-off) nuts. Size: 40mm x 40mm/ 45mm x 45mm/ 50mm x 50mm
Pale tops		Split-tripple point or single point for high security. Rounded or rounded and notched for ety.
Fittings		Rails and pales are fitted using 'rivets & collars' or rounded bolts with permacone nuts (snap-off / anti-vandal).
Link Plates		Link plates, AKA 'Fish Plates' fit through the holes is the steel fencing posts and join the rails together.

Steel palisade fencing Finishes

Available as 'Hot Dipped Galvanised' or 'Galvanised & Polyester Powder Coated to any colour'.

Steel palisade fencing Finishes Application

Palisade fencing is a style of security fence with tightly spaced vertical uprights, called pales. Pales come in various shapes and sizes. The security level you are trying to achieve will determine what shape and how close the pales will be.

Each pale has a specific design cut into the top. Designs range from flat tops to trident styles and splayed tips with sharp points. As result, making palisade fencing very difficult to climb over.

Today’s palisade fencing is manufactured from steel. However, that wan’t always the case.

*Electricity Providers and Regional Networks

*Water Industry

*Telecoms Industry

*Police and Law enforcement

*Railway Line/Track Protection

*Motorways and Highway Protection

*Channel tunnel and European Transport networks

*Schools, Colleges & Universities

*Research Laboratories

2.4m Galvanized PVC Coated Green Tubular Steel Fencing Palisade 65*2.5mm 0

2.4m Galvanized PVC Coated Green Tubular Steel Fencing Palisade 65*2.5mm 1

2.4m Galvanized PVC Coated Green Tubular Steel Fencing Palisade 65*2.5mm 2

2.4m Galvanized PVC Coated Green Tubular Steel Fencing Palisade 65*2.5mm 3
