Easy Install Wire Mesh Demister Pad 431 Air Liquid Filtration 100-5000mm Diameter

China Anping yuanhai wire mesh products Co., Ltd certification
China Anping yuanhai wire mesh products Co., Ltd certification
Thanks for your kindly hospitality. Your company is very professional , we are very satisfied with your expanded metel sheet, we will have nice cooperation in the near future.

—— Roger Hopkins

Good company with nice service and high quality and high reputation. The stainless steel wire mesh is good quality,one of our reliable supplier , goods are delivered in time and nice package.

—— Mr.mosharaf hossain

Received ur Gabion Mesh,Thanks for your good after-sale service. Excellent training and technology support helps me a lot.

—— Tshediso Sedie

I'm Online Chat Now

Easy Install Wire Mesh Demister Pad 431 Air Liquid Filtration 100-5000mm Diameter

Easy Install Wire Mesh Demister Pad 431 Air Liquid Filtration 100-5000mm Diameter
Easy Install Wire Mesh Demister Pad 431 Air Liquid Filtration 100-5000mm Diameter Easy Install Wire Mesh Demister Pad 431 Air Liquid Filtration 100-5000mm Diameter

Large Image :  Easy Install Wire Mesh Demister Pad 431 Air Liquid Filtration 100-5000mm Diameter

Product Details:
Place of Origin: Anping,Hebei
Brand Name: YH
Certification: ISO 9001:2008
Model Number: YH-06
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Wooden Case or as request
Delivery Time: 7 days after payment
Payment Terms: T/T
Supply Ability: 2600 Sets per Week demister pad
Detailed Product Description
Thickness: 150-200mm Or On Request Usage: Air & Liquid Filtration
Material: Stainless Steel Wire Size: 100-5000mm Diameter
Shape: Circular, Square,etc. Filter Rating: 99%
Type: Filter Elements Wire Diameter: 0.08mm-0.30mm
MOQ: 1 Set Response Time: Within 24 Hours
High Light:

stainless steel mesh pad

,

mesh pad mist eliminator

Stianless Steel 304 Air Purification Drift Eliminator Wire Mesh Demister Pad 431





Description


Wire mesh demister pad is supplied in standard, high efficiency and high permeability. Demister Pads are essentially porous blankets of carefully knitted wire mesh designed and constructed to efficiently abate mist particles. Demister pad is mainly used to eliminate streams with diameter of more than 3μm to 5μm.
Wire diameter used for the knitting directly affects flow, dirt holding capacity, pressure drop and cost. Knitted wire mesh demister pad is used to separate in the most efficient manner the very fine drops carried away by a gas or steam, either at a boiling stage, vacuum evaporation or bubbling of a liquid.



Product Feature


1. High collection efficiency of up to 99% of fluid at velocity of 1 to 8m/sec
2. Provides free area of up to 98% for operation and low pressure drop (0.1" ~ 1.0" W/G)
3. A variety of materials in accordance with temperature and corrosion resistance
4. Easy to install by using manhole. Usable without any restriction and replaceable with existing facilities
5. Designed for self - cleaning (semi - permanent and economical)



Product Specification



Item

Bulk Density
Kg/m3

Surface Area
m2/m3

Voidage
ε

EM-80 80 155 98.9
EM-120 120 210 98.5
EM-144 144 275 98.2
EM-160 160 310 98.0
EM-300 300 575 96.2
Above are the standard parameters, also we can design according to the customer requirement.



Application



* Elimination of toxic air pollutants
* Reduction of solvent losses in absorbers ,scrubbers and distillation equipment
* Optimization in kettles ,reboilers and crystallizers
* Elimination of entrainment
* Used in liquid -liquid systems
* Used as gaskets in cable, automobile and computer industry
* Gas-liquid ,solid-liquid separation
* Desalination plants


About our company

1. Is your company a manufacturer or a trading company?
We are a manufacturer located in Anping County, China.
2. Do you have inport-export right?
Yes, we do. Our factory has been certificated as an import-export enterprise.

3. What is your payment mode?
30% in advance and 70% before delivery by T/T, WESTERN UNION, L/C or negotiated.

4. How about your packing?
We usually packed in plastic material inside and then wooden box outside.

5. How long is your delivery?
Usually 10-20 days after order confirmed, according the quantity ordered.

6. Is it sample available?
Yes, small pieces of sample are available in our company.
