ASTM PVC Coated Stone Rock 80*100mm Gabion Box

ASTM PVC Coated Stone Rock 80*100mm Gabion Box
ASTM PVC Coated Stone Rock 80*100mm Gabion Box ASTM PVC Coated Stone Rock 80*100mm Gabion Box ASTM PVC Coated Stone Rock 80*100mm Gabion Box ASTM PVC Coated Stone Rock 80*100mm Gabion Box

Large Image :  ASTM PVC Coated Stone Rock 80*100mm Gabion Box

Product Details:
Place of Origin: HEBEI, CHINA
Brand Name: YUANHAI
Certification: ISO9001
Model Number: YH-G01
Payment & Shipping Terms:
Minimum Order Quantity: 50m2
Price: Negotiable
Packaging Details: According to customers'requirement,for gabion basket/gabion wire mesh for protecting dam
Supply Ability: 5000m2 per month
Detailed Product Description
Material: Galvanized Iron Wire Feature: Anti-corrosion
Surface Treatment: Electric Galvanized/Hot-dipped Galvanized/PVC-coated Aperture: 6*8,8*10,10*12cm,etc
Usage: Retaining Walls,Beach Reinforcement Key Words: Defence Wall
High Light:

80*100mm Gabion Wire Mesh

,

Garden Gabion Wire Mesh

ASTM Standard PVC Coated Stone Rock Gabion Box For Garden 80*100mm OEM





Gabion Box Description



Gabion wire mesh are used in slope support, Foundation pit, mountain rock face mesh shotcrete Gabion ,gabion cages cages Slope vegetation (green), railroad highway isolation guarding block. it also can be made into cages, nets mats, scour protection of rivers, levees and seawalls, reservoirs and river closure with a cage. The most serious disaster for river is River water flow make it destroy, Causing flooding, resulting in significant loss of life and property and massive soil erosion. In dealing with these issues when the ecological grid structure applied to become one of the best solutions, it can make the river banks receive permanent protection.



Gabion Box Materials



Low carbon steel wire, stainless steel wire, electro galvanized wire, hot-galvanized wire, heavily galvanized wire, PVC-coated.

Weaving processing: Twisted before galvanized, weaving after galvanized.

Gabion Size:

2m× 1m× 1m, 3m× 1m× 1m, 4m× 1m× 1m, 2m× 1m× 0.5m, 4m× 1m× 0.5m. Customer orders available.



Gabion Box Feature



(1) It is convenient to use, and can be used only by tiling the net surface into wall surfaces and building cement;

(2) the construction is simple and does not need special technology;

(3) Strong ability to resist natural damage, corrosion and adverse weather effects;

(4) can withstand large-scale deformation without collapsing. It plays a role in fixing heat preservation and heat insulation.

(5) The excellent technological foundation ensures the uniformity of coating thickness and has stronger corrosion resistance;

(6) Save transportation costs. It can be shrunk into small rolls and wrapped in moisture-proof paper, occupying little space.



Gabion Box Applications



The gabion box or gabion basket is unfolded and laid on prepares ground. The kinks and creases in the boxes can be easily stamped out and leveled manually. The individual sheets are straightened flat and then systematically folded to form an exact rectangular shape. All the sides diaphragms are laced with lacing wire with lacing procedure. The boxes or group of laced boxes are positioned at the required location to match the structural design accurately.



Gabion Box Specification



Specification
Opening(mm) Wire diameter metal wire(mm) Wire diameter PVC coated/inner/outside(mm) Strands
60 X 80 f 2.0/2.8 f 2.0/3.0-2.5/3.5 3
80 X 100 f 2.0/3.2 f 2.0/3.2-2.8/3.8 3
80 X 120 f 2.0/3.2 f 2.0/3.2-2.8/3.8 3
100 X 120 f 2.0/3.4 f 2.0/3.0-2.8/3.8 3
100 X 150 f 2.0/3.4 f 2.0/3.0-2.8/3.8 3
120 X 150 f 2.0/4.0 f 2.0/3.0-3.0/4.0 3





ASTM PVC Coated Stone Rock 80*100mm Gabion Box 0
