Anti Corrosion Galvanized 5.0mm Gabion Box

Anti Corrosion  Galvanized 5.0mm Gabion Box
Anti Corrosion  Galvanized 5.0mm Gabion Box Anti Corrosion  Galvanized 5.0mm Gabion Box Anti Corrosion  Galvanized 5.0mm Gabion Box

Large Image :  Anti Corrosion Galvanized 5.0mm Gabion Box

Product Details:
Place of Origin: HEBEI, CHINA
Brand Name: YUANHAI
Certification: ISO9001
Model Number: YH-G01
Payment & Shipping Terms:
Minimum Order Quantity: 50m2
Price: Negotiable
Packaging Details: According to customers'requirement,for gabion basket/gabion wire mesh for protecting dam
Supply Ability: 5000m2 per month
Detailed Product Description
Material: Galvanized Iron Wire Aperture: 6*8,8*10,10*12cm,etc
Wire Gauge: 2.0mm-5.0mm Size: 2m*1m*1m (or Customized)
Weave: Gabion Matresses,Retaining Wall Feature: Anti-corrosion, Easily Assembled
High Light:

5.0mm gabion mesh

,

5.0mm wire mesh retaining wall

Galvanized Gabion Box For Retaining Wall Military Sand Wall





Gabion Box Description



Gabion box can be used for making slope, rock,slope vegetation,rail-way or highway guardrail mesh stable. Also it can be made
into basket, mesh mat for protecting dam which easily ruined by flood and lead to property losses. Therefore, application of
gabion basket is the best solution of solving the problem that give dams lasting protection.



Gabion Box Advantages



corrosion prevention ,eletrostatic prevention ,age resistance ,corrosion-resistance ,compressive resistance ,sheaving resistance and improving the protective function in the highly polluted environment .This kind of mesh mainly used in river , sea and highly polluted area .



Gabion Basket Specification



Aperture (mm) Mesh wire (mm) Selevage wire (mm) Lacing wire(mm) Max width (m)
60x80 2.0-3.0mm 3.0-4.0mm 2.2mm 4m
80x100 2.0-3.0mm 3.0-4.0mm 2.2mm 4m
80x120 2.0-3.0mm 3.0-4.0mm 2.2mm 4m
100x120 2.0-3.0mm 3.0-4.0mm 2.2mm 4m
100x150 2.0-3.0mm 3.0-4.0mm 2.2mm 4m
120x150 2.0-3.0mm 3.0-4.0mm 2.2mm 4m



Length(m) Width(m) Heigh(m) Diaphragm Volum Tolerance
2.0 1.0 0.3 1 0.6

Length:+/-3%

Width:+/-5%

Heigh:+/-5%

3.0 1.0 0.3 2 0.9
4.0 1.0 0.3 3 1.2
2.0 1.0 0.5 1 1.0
3.0 1.0 0.5 2 1.5
4.0 1.0 0.5 3 2.0
1.0 1.0 1.0 0 1.0
1.5 1.0 1.0 0 1.5
2.0 1.0 1.0 1 2.0
3.0 1.0 1.0 2 3.0
4.0 1.0 1.0 3 4.0



Gabion Basket Application

  • Retaining Walls
  • Temporary Bridge Abutments
  • Noise Barriers
  • Beach Reinforcement
  • River Bank Revetment
  • Landscaped Boundaries
  • Drainage Channels and Culverts
  • Railway Embankments
  • Safety Barriers
