358 High Security Fence Anti Climb Anti Cut Heavy Duty Protection
Product introduction:
The 358 High Security Fence (also known as Prison Mesh Fence) is a premium perimeter security solution designed for maximum intrusion prevention.
Our 358 Security Fencing (Prison Mesh Fence) is engineered to deliver maximum perimeter security through its unique 12.7×76.2mm (0.5"×3") rectangular mesh pattern. This heavy-duty fencing system combines anti-climb and anti-cut properties with exceptional durability, making it the preferred choice for correctional facilities, military installations, and high-security commercial sites.
Constructed from heavy-duty 5-6mm steel wire with hot-dip galvanized (85μm+) or powder-coated finish, it offers decades of maintenance-free service even in harsh environments.
Technical Specifications:
Core Parameters:
| Component |
Specification |
| Mesh Opening |
12.7×76.2mm (Standard) |
| Wire Diameter |
3.0/3.5/4.0mm (Customizable) |
| Panel Dimensions |
Height: 1.2-6.0m (Custom) Width: 2.0-3.1m |
| Post Options |
Square: 60×60mm/80×80mm (2.0-3.0mm thickness) Rectangular: 40×60mm to 80×100mm |
Standard Configurations:
| Model |
2.1m |
2.4m |
3.0m |
| Height |
2134mm |
2438mm |
2997mm |
| Width |
2515mm |
2515mm |
2515mm |
| Wire Dia. |
4mm |
4mm |
4mm |
| Post Size |
60×60×3mm |
60×60×3mm |
60×60×3mm |
| Post Length |
2.8m |
3.1m |
4.0m |
| Fixings |
8 |
9 |
11 |
Key Features:
Advanced Security Performance:
Anti-climb mesh design prevents footholds
4mm thick wires resist cutting tools (BS EN 10223-3 compliant)
Tamper-proof welded construction
Superior Durability:
Hot-dip galvanized coating (85μm minimum)
Optional PVC/powder coating (RAL colors available)
25+ year service life in harsh environments
Flexible Configuration:
Custom heights up to 6.0m
Multiple post options (SHS/RHS)
Various wire diameters (3.0-6.0mm)
Surface Treatment Options:
Standard: Hot-dip galvanized (EN ISO 1461)
Enhanced: Galvanized + PVC coated (2.0mm thickness)
Premium: Galvanized + powder coated (RAL color matched)
Available Colors: RAL 6005 (Green), RAL 7016 (Gray), or any RAL custom color
Typical Applications:
Correctional facilities and detention centers
Military bases and government buildings
Airport perimeters and power plants
High-security commercial properties
Critical infrastructure protection
Installation & Compliance:
Modular panel system for rapid deployment
Meets CPNI LPS 1175 SR3/SR4 security ratings
Complies with ASTM F567 and UK Home Office standards
Custom Solutions Available: Contact our engineering team for project-specific configurations, including non-standard dimensions, special fixings, or enhanced security features.
