Double Twisted Hexagonal Gabion Wire Mesh Landscape and Civil Engineering Solutions
Product Description:
Our Double Twisted Hexagonal Gabion Wire Mesh is a versatile and durable solution for landscaping, erosion control, and civil engineering projects. Featuring a hexagonal mesh structure with double-twist wire technology, this gabion system provides superior strength, flexibility, and longevity for both functional and aesthetic applications. Made from high-tensile, corrosion-resistant steel wire, it is ideal for constructing retaining walls, riverbank protection, and decorative landscape features.
Key Advantages:
1.Enhanced Structural Integrity
- Double-twisted hexagonal weave prevents unraveling even if wires are cut
- High-tensile steel wire (350-500 MPa) resists deformation under heavy loads
- Flexible design adapts to uneven terrain and ground movement
2.Corrosion Resistance
- Hot-dip galvanized coating (200-300g/m²) for long-term rust protection
- PVC-coated options (RAL colors) for extreme environments or aesthetic needs
- Service life of 50+ years in normal conditions
3.Eco-Friendly & Permeable
- Allows natural drainage and vegetation growth
- Uses natural stone fillings (quarried or recycled materials)
- Reduces hydrostatic pressure in retaining structures
4.Easy Installation
- Pre-assembled panels with spiral connectors for quick assembly
- No specialized tools required
- Modular design for custom configurations
Technical Specifications:
| Parameter |
Specification |
| Mesh Type |
Hexagonal (Double Twisted) |
| Mesh Size |
60x80mm, 80x100mm, 100x120mm (Custom Available) |
| Wire Diameter |
2.0mm (Mesh), 2.7mm (Selvedge), 3.4mm (Lacing) |
| Coating |
Galvanized (Standard) / PVC-Coated (Optional) |
| Panel Size |
2m x 1m x 1m (LxWxH) / Custom Dimensions |
| Tensile Strength |
≥350 MPa (Wire) |
| Standards |
EN 10223-3, ASTM A975, ISO 9001 |
Applications:
1.Landscaping:
- Decorative garden walls and terraces
- Water features and fountain bases
- Noise reduction barriers
2.Civil Engineering:
- Riverbank and coastal erosion control
- Retaining walls for roads and railways
- Slope stabilization and landslide prevention
3.Infrastructure:
- Bridge abutment protection
- Stormwater management systems
- Flood defense barriers
4.Industrial:
- Quarry rockfall protection
- Mining site reinforcement
Manufacturing Process:
Wire Drawing
High-carbon steel wire cold-drawn to precise diameters (2.0-3.4mm)
Zinc coating applied via hot-dip galvanizing (450°C immersion)
Mesh Weaving
Automated double-twist machines create hexagonal mesh
Reinforced selvedge edges for panel rigidity
Panel Assembly
Mesh panels connected with spiral binders or lacing wire
Folded into gabion baskets for shipping
FAQ:
Q: What stone size is recommended?
A: 1.5-2x the mesh size (e.g., 100-200mm stones for 80x100mm mesh).
Q: How long does installation take?
A: A 10m² wall can be assembled in 1-2 days by a 3-person crew.
Q: Can plants grow through the mesh?
A: Yes – the open structure allows natural vegetation integration.
Q: Is heavy machinery needed?
A: Only for large projects – manual installation is standard.
Q: Warranty period?
A: 10-year structural warranty (excludes environmental damage).
Contact us for:
Free engineering design support
Site-specific corrosion resistance analysis
Bulk project discounts
